Ubiquiti NanoStation M5 (NSM5) | 5 GHz 16 dBi MIMO CPE

Ubiquiti NanoStation M5 (NSM5) | 5 GHz 16 dBi MIMO CPE

• Processor Specs: Atheros MIPS 24KC, 400MHz
• Memory Information: 32MB SDRAM, 8MB Flash
• Networking Interface: 1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interface
• Power Supply: 24V, 0.5A POE
• 150+ Mbps real outdoor throughput and up to 15km+ range"

Ubiquiti NanoStation M5 (NSM5) Overview

The Ubiquiti NanoStation M5 (NSM5) is a professional outdoor Customer Premises Equipment designed for reliable 5GHz wireless networks. This device combines high gain, efficient throughput, and a durable enclosure to deliver long-range connectivity in point-to-point or point-to-multipoint deployments.

Ubiquiti NanoStation M5 (NSM5) Compact and Weather-Resistant Design

The NanoStation M5 has a slim profile measuring just 294 by 31 by 80 millimeters, with a weight of around 400 grams. Its enclosure is made from UV-stabilized plastic engineered to withstand harsh outdoor conditions, including extreme temperatures, moisture, and sunlight. The included pole-mount kit makes it easy to install securely on masts or poles.

Ubiquiti NanoStation M5 (NSM5) Dual Ethernet Ports and Passive PoE

This device features two 10/100 Mbps Ethernet ports. One port offers passive PoE passthrough capability, allowing you to power a second device such as a surveillance camera. The NanoStation M5 operates using 24V passive PoE, consuming less than 8 watts of power, making it energy-efficient and simple to deploy.

Ubiquiti NanoStation M5 (NSM5) 5GHz Radio with 16dBi Gain

The integrated antenna delivers between 14.6 and 16.1 dBi gain, producing a narrow beam that effectively focuses signal power for improved range and reliability. The horizontal beamwidth is approximately 43 degrees, while the vertical is about 41 degrees, giving you the directional coverage needed for precise alignment and strong signal stability.

Ubiquiti NanoStation M5 (NSM5) 2x2 MIMO Performance

Using 2x2 MIMO technology, the NanoStation M5 increases throughput and ensures robust communication even in challenging environments. Real-world TCP/IP performance reaches 150 Mbps or more, and short-range links can exceed 300 Mbps. When properly aligned, this device is capable of maintaining stable connections over distances of up to 15 kilometers.

Ubiquiti NanoStation M5 (NSM5) airMAX TDMA Protocol

The NanoStation M5 uses Ubiquiti’s airMAX TDMA protocol to coordinate transmissions into time slots. This system eliminates hidden-node collisions, reduces latency, and improves overall network efficiency, making it ideal for real-time applications like video streaming and voice-over-IP.

Ubiquiti NanoStation M5 (NSM5) Rugged Outdoor Reliability

Designed to operate between -30°C and 75°C, this device is well-suited to almost any outdoor climate. It meets industrial standards for shock and vibration resistance, ensuring it continues to perform in demanding conditions. Certifications include FCC, IC, CE, RoHS, and NDAA compliance.

Ubiquiti NanoStation M5 (NSM5) Ideal Use Cases

The NanoStation M5 is a versatile solution for:

• Long-distance point-to-point wireless bridges between buildings or sites

• Client devices in point-to-multipoint airMAX networks

• Extending network coverage to remote areas such as barns, workshops, or surveillance zones

• Wireless backhaul for security camera systems or outdoor networks

Ubiquiti NanoStation M5 (NSM5) Technical Specifications

Key technical highlights:

• Frequency Range: 5GHz (5170–5875 MHz)

• Antenna Gain: 14.6–16.1 dBi

• MIMO Configuration: 2x2

• Beamwidth: ~43° horizontal, ~41° vertical

• Ethernet Ports: 2x 10/100 Mbps

• PoE Passthrough: Yes (software-enabled)

• Power Input: 24V passive PoE

• Power Consumption: Max 8 watts

• Dimensions: 294 x 31 x 80 mm

• Weight: 400 grams

• Operating Temperature: -30°C to 75°C

• Enclosure: UV-stabilized outdoor casing

• Certifications: FCC, IC, CE, RoHS, NDAA

Ubiquiti NanoStation M5 (NSM5) Final Thoughts

The Ubiquiti NanoStation M5 (NSM5) combines powerful performance, long-range coverage, and durable construction in a compact form factor. Whether you are building a high-speed point-to-point link or extending broadband service to a remote location, this device delivers reliable results in professional outdoor networking environments.
