Ubiquiti LiteBeam Gen 2 5AC LBE‑5AC‑Gen2

Ubiquiti LiteBeam Gen 2 LBE‑5AC‑Gen2 Overview

The Ubiquiti LiteBeam Gen 2 5AC (LBE‑5AC‑Gen2) is a sleek, high-performance outdoor CPE engineered to deliver long-range wireless connectivity. Its 23 dBi reflector antenna and precision beamforming ensure stable, high-speed links up to 25 km, ideal for point-to-point (PtP) or point-to-multipoint (PtMP) applications in urban, suburban, and rural settings.

High-Gain 23 dBi Antenna and Focused Beam

With a large 23 dBi dish antenna, the LiteBeam Gen 2 captures weak signals over long distances while rejecting interference from the side. The ultra-narrow beam enhances signal fidelity, making it highly effective for CPE deployments requiring reliable, long-reach links.

Integrated RF Design for Maximum Efficiency

This Gen 2 model features integrated radios with 2×2 MIMO architecture, delivering superior spectral efficiency and robust data rates. Built for the 5 GHz band, it supports up to 867 Mbps real-world throughput, making it suitable for bandwidth-intensive activities like video streaming, VoIP, and large file transfers.

Innovative Dish-Alignment Design

Installation is simplified with the LiteBeam’s patented dish-alignment mount and captive fasteners. Using an ultra-precise ball-joint, users can align the antenna to within fractions of a degree, reducing setup time and maximizing link performance.

Robust, Weather-Resistant Construction

Designed for outdoor use, the LiteBeam Gen 2 is encased in durable materials rated for operation in extreme conditions (-40 °C to 80 °C). Its wind-resistant design and sealed enclosure ensure reliability in every climate.

Easy Installation and Power Efficiency

Powered via 24 V passive PoE, the device draws minimal power (under 10 W) while delivering Gigabit Ethernet connectivity. This efficient power design supports versatile deployment even in remote areas.

airOS 8 Management and Monitoring

Equipped with airOS 8, the LiteBeam provides an intuitive interface with features like real-time signal meters, spectral analysis, and firmware management. Both standalone management and remote control through Ubiquiti’s UNMS ecosystem are supported.

Ideal Use Cases

The Ubiquiti LiteBeam Gen 2 LBE‑5AC‑Gen2 is perfect for:

• Establishing long-range PtP links between buildings or towers

• Serving as CPE for rural broadband deployments

• Extending wireless coverage to outbuildings or remote sites

• Temporary or event-based connectivity requiring fast setup

Technical Specifications

• Frequency Range: 5150–5875 MHz

• Antenna Gain: 23 dBi

• MIMO: 2×2

• Max Throughput: Real-world up to 867 Mbps

• Ethernet Port: 1× Gigabit Ethernet

• Power Input: 24 V passive PoE

• Power Consumption: ~10 W

• Operating Temperature: –40 °C to 80 °C

• Dish Diameter: 26 cm

• Wind Survivability: High (exact spec similar to 200 km/h class)

LiteBeam Gen 2 LBE‑5AC‑Gen2 Final Thoughts

The LiteBeam Gen 2 LBE‑5AC‑Gen2 combines high-gain performance, precise alignment, and rugged durability in an affordable and compact outdoor CPE. Whether for point-to-point bridging, rural CPE deployment, or high-throughput wireless backhaul, this device delivers exceptional value and reliability. Choose the LiteBeam Gen 2 for long-range, high-performance wireless networking.
