Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP
Key Specifications
- Product Name: Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP
- Brand: Mercusys
- Model: MS106LP
- Product Type: Unmanaged PoE+ desktop switch
- Ports: 6 × 10/100Mbps RJ45 ports
- PoE Ports: 4 × PoE+ ports
- PoE Standard: IEEE 802.3af/at
- Total PoE Budget: Up to 40W
- Maximum PoE Output per Port: Up to 30W
- Switching Capacity: 1.2Gbps
- Forwarding Rate: 0.893Mpps
- Transmission Distance: Up to 250 meters in Extend Mode
- Network Standards: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
- Auto Negotiation: Supported on all ports
- Auto MDI/MDIX: Supported on all ports
- Connectivity and Compatibility: Compatible with IP cameras, wireless access points, VoIP phones, network video recorders, routers, and other Ethernet-enabled devices
- Management: Unmanaged plug-and-play operation
- Power Supply: External power adapter
- Design: Desktop and wall-mountable form factor
- Color: Black
- Ideal For: IP surveillance systems, small offices, retail stores, and home networks
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Overview
The Mercusys MS106LP is a compact unmanaged PoE+ switch designed to simplify network deployments by delivering both data and power over a single Ethernet cable.
Featuring six Fast Ethernet ports, including four PoE+ ports with a total power budget of up to 40W, the switch is ideal for powering IP cameras, wireless access points, and VoIP phones.
Its Extend Mode supports PoE transmission distances of up to 250 meters, making it especially suitable for surveillance installations.
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Price
| Product | Price (KSh) |
|---|---|
| Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP | 2,600 |
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Full Specifications
| Specification | Details |
|---|---|
| Brand | Mercusys |
| Model | MS106LP |
| Product Type | Unmanaged PoE+ switch |
| Ports | 6 × 10/100Mbps RJ45 |
| PoE Ports | 4 |
| PoE Standard | IEEE 802.3af/at |
| Total PoE Budget | 40W |
| Maximum PoE per Port | 30W |
| Switching Capacity | 1.2Gbps |
| Forwarding Rate | 0.893Mpps |
| Extend Mode Distance | Up to 250m |
| Network Standards | IEEE 802.3i/u/x, IEEE 802.3af/at |
| Management | Unmanaged |
| Mounting Options | Desktop, wall-mountable |
| Color | Black |
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Design & Build Quality
The MS106LP features a compact and durable design suitable for various deployment scenarios.
Key design features include:
- Compact desktop form factor
- Durable metal enclosure
- Fanless design for silent operation
- LED indicators for port and PoE status
- Wall-mounting support
- Dedicated Extend Mode switch
Its fanless construction ensures quiet and reliable operation in offices and surveillance environments.
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Performance
The MS106LP delivers dependable networking and power distribution for PoE-enabled devices.
Key performance benefits include:
- Four PoE+ ports for simplified installations
- Total PoE budget of up to 40W
- Extend Mode supports up to 250-meter transmission
- Plug-and-play deployment with no configuration required
- Auto MDI/MDIX support eliminates crossover cable requirements
- IEEE 802.3x flow control improves transmission reliability
- Fanless design ensures silent operation
The switch is particularly well suited for IP surveillance systems and small office deployments.
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Connectivity and Compatibility
- Ports: 6 × 10/100Mbps RJ45 Ethernet ports
- PoE Ports: 4 × IEEE 802.3af/at compliant ports
- PoE Budget: Up to 40W total
- Extend Mode: Up to 250 meters
Compatible Devices:
- IP cameras
- Wireless access points
- VoIP phones
- Network video recorders (NVRs)
- Routers
- Desktop computers
- Smart TVs
The switch works with most IEEE 802.3af/at compliant devices and standard Ethernet equipment.
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Applications
- CCTV and IP surveillance systems
- Small office networking
- Retail stores
- Home security installations
- Wireless access point deployments
- VoIP phone systems
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Pros & Cons
| Pros | Cons |
|---|---|
| Four PoE+ ports simplify installation | Limited to 10/100Mbps speeds |
| Extend Mode supports up to 250m | No Gigabit Ethernet support |
| Fanless and silent operation | Unmanaged features only |
| Compact wall-mountable design | Limited 40W PoE budget |
| Plug-and-play setup | Not suitable for high-bandwidth applications |
Frequently Asked Questions (FAQs)
What is the price of the Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP in Kenya?
The Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP is available in Kenya for KSh 2,600.
How many PoE ports does the switch have?
The MS106LP features 4 PoE+ ports compliant with IEEE 802.3af/at standards.
What is the total PoE power budget?
The switch offers a total PoE budget of up to 40W.
Does the switch support long-range PoE transmission?
Yes. In Extend Mode, the switch supports PoE transmission distances of up to 250 meters.
Is any configuration required?
No. The MS106LP is an unmanaged switch with plug-and-play functionality.
Mercusys 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - MS106LP Conclusion
The Mercusys MS106LP is an affordable and practical PoE+ switch for surveillance systems and small business networks.
At KSh 2,600, it delivers reliable Fast Ethernet connectivity, four PoE+ ports, and long-range transmission capabilities in a compact, easy-to-deploy package.
