AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher

• Compact 4-Channel Video Switcher
• 2 x HDMI and 2 x SDI Autodetected Inputs
• 1 x HDMI Multiview, 2 x HDMI PGM Outputs
• USB Type-C Output for Streaming
• Supports up to 1080p60 Video I/O
• Luma/Chroma Key, Mix/Fade/Wipe Effects
• T-Bar, Auto, and Cut Transitions
• Audio Mixing and PiP Layout
• Supports PNG, JPG, and BMP Logo Overlays

Description

Add professional video switching and audio mixing flexibility to your concert productions, house of worship, educational forum, or live sports programming with this HVS0403U Micro 4-Channel SDI & HDMI Video Switcher from AVMATRIX. Boasting two HDMI and two SDI autodetected inputs, the HVS0403U is a compact and user-friendly video switcher loaded with powerful features, including luma and chroma keying, mix/fade/wipe effects, audio mixing, and a picture-in-picture (PiP) or picture-on-picture (PoP) layout, using tactile functions such as auto and cut transitions or with the T-bar.

Bring in four separate sources for switching up to 1080p60 video with embedded audio, or mix in additional audio originating from two analog stereo 3.5mm mic/line inputs. An HDMI output with multiview support provides ideal previewing functions, and two HDMI program outputs with scaling features give you flexibility for sending simultaneous signals to a display for live events and a recording terminal for editorial consideration. There is also a USB Type-C video output to connect to a computer for video capture and livestreaming, while a LAN port enables you to control the switcher using software via IP.

Logo overlays are supported from a variety of different image file formats, including PNG, JPG, and BMP, and you have the option of capturing up to 16 screenshots and storing up to 16 images using the USB Type-A input with 39 default patterns and two color generators. A tally interface supports GPIO, still frame, mute, and fade-to-black (FTB) functionality.

AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher provides a Scaled Output and Multiview

The switcher supports multiview formats, including 1080p, 1080i, 720p, 576i, and 480p HDMI and SDI signals. Each output supports up/down scaling and can be configured as HDMI/SDI source, PVW, PGM, clean PGM, and multiview.

AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher has a USB Capture for Streaming

Connect the switcher to a computer via the USB Type-C output and use software like OBS, PotPlayer, or vMix to realize livestreaming on YouTube, Facebook, Twitter, and other social media platforms.

AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher has Upstream and Downstream Keying

The switcher supports chroma and luma key for keying off blue/green and black background colors for virtual studio or live event applications.

AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher has Transition Effects

There are wipe (11 x 2 patterns), mix, and dip transition effects available using the T-bar or Auto button function, and users can also transition to different shots by switching via the Cut button.

AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher has a Powerful Media Management

The media management functions feature 39 preset patterns, and users can import images from a USB thumb drive or capture and store the screenshot image originating from SDI1, SDI2, HDMI3, HDMI4, clean PGM, and PGM.

AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher enables Audio Mixing and Audio Follows Video

Easily mix the embedded audio from the two HDMI and two SDI sources or set the embedded audio function to AFV (audio follows video) mode. You can also bring in two external audio sources via the unit’s two 3.5mm analog (mic/line) inputs.

AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher has a PC Control Software

A free software can be downloaded from the manufacturer’s website allowing users to control all settings of the device via IP.
