Huawei eKit AP761 WiFi 6 Access Point with PoE

Product Key Features – Huawei eKit AP761 WiFi 6 Access Point with PoE

• Dual-band Wi-Fi 6 (802.11ax) offering up to 1775Mbps total throughput

• 2.4GHz band delivers 575Mbps and 5GHz band supports up to 1200Mbps

• Supports up to 1024 concurrent users (512 per radio)

• Advanced MU-MIMO, OFDMA, and 1024-QAM technologies for high-density environments

• Smart antenna and beamforming technology for wider and stronger coverage

• IP68-rated waterproof and dustproof housing suitable for outdoor and indoor use

• Wide operating temperature range from –40°C to +65°C with surge protection

• Power over Ethernet (PoE/PoE+) and 12V DC power input for flexible deployment

• 2.5 Gigabit Ethernet uplink port with combo SFP for fiber connectivity

• Built-in BLE 5.2 and USB port for IoT integration and local management

• Advanced security features including WPA3, VLAN, rogue AP detection, and firewall

Discover the Huawei eKit AP761 WiFi 6 Access Point with PoE

The Huawei eKit AP761 WiFi 6 Access Point with PoE is designed to deliver high-speed, reliable, and secure wireless connectivity in both indoor and outdoor environments. With a rugged IP68-rated enclosure, this device is built to withstand harsh weather conditions, dust, and moisture, making it an ideal solution for campuses, factories, warehouses, large retail spaces, and outdoor venues. The AP761 harnesses the power of Wi-Fi 6 to provide a significant boost in speed, capacity, and efficiency over previous Wi-Fi generations.

Superior Dual-Band Connectivity with Huawei eKit AP761 WiFi 6 Access Point with PoE

Equipped with dual-band Wi-Fi 6 radios, the Huawei eKit AP761 offers a combined throughput of up to 1775Mbps. The 2.4GHz band delivers 575Mbps while the 5GHz band achieves speeds up to 1200Mbps. This access point is engineered to support bandwidth-intensive applications such as video conferencing, remote collaboration, cloud services, and large file transfers. It ensures seamless and fast wireless performance even in environments with high numbers of connected devices.

High User Density Performance with Huawei eKit AP761 WiFi 6 Access Point with PoE

The Huawei eKit AP761 is designed for high-density environments where many devices are connected simultaneously. Supporting up to 1024 concurrent users (512 per radio), it leverages advanced Wi-Fi 6 technologies such as MU-MIMO and OFDMA to divide channels efficiently among multiple clients. This results in lower latency, higher throughput, and stable performance even when the network is under heavy load.

Rugged and Weatherproof Design of Huawei eKit AP761 WiFi 6 Access Point with PoE

This access point features an IP68-rated enclosure, ensuring complete protection from dust, rain, humidity, and extreme temperatures ranging from –40°C to +65°C. It is also equipped with surge protection to safeguard against electrical disturbances. Whether mounted on a wall, ceiling, or pole, the AP761 is designed to perform reliably in challenging environments, both indoors and outdoors.

Flexible Power and Networking with Huawei eKit AP761 WiFi 6 Access Point with PoE

The Huawei eKit AP761 simplifies deployment by offering multiple power options, including PoE/PoE+ and 12V DC input. The 2.5 Gigabit Ethernet uplink port with combo SFP provides flexible connectivity, whether through copper or fiber links. This combination of power and networking options enables easy deployment in various infrastructure scenarios without the need for extensive rewiring.

Extended Coverage and Smart Antenna Technology in Huawei eKit AP761 WiFi 6 Access Point with PoE

Smart antenna technology and beamforming capabilities enable the Huawei eKit AP761 to deliver a stronger and more focused wireless signal directly to client devices. This enhances coverage, minimizes interference, and improves overall signal stability. Users benefit from a reliable wireless experience across large indoor spaces or wide outdoor areas without dead zones.

Secure and Reliable Networking with Huawei eKit AP761 WiFi 6 Access Point with PoE

The Huawei eKit AP761 is built with enterprise-grade security in mind. It supports WPA3 encryption, VLAN segmentation, MAC filtering, and rogue AP detection to protect the network from unauthorized access and threats. Additionally, the AP includes firewall capabilities and advanced network isolation features to ensure data integrity and privacy for connected users.

Simplified Management and Scalability with Huawei eKit AP761 WiFi 6 Access Point with PoE

The AP761 supports Huawei’s CloudCampus for centralized cloud-based management, as well as traditional Fat and Fit operating modes for local or controller-based management. The built-in BLE 5.2 module allows administrators to perform proximity-based configuration and quick deployment using mobile devices. This simplifies large-scale deployments while ensuring easy monitoring, troubleshooting, and maintenance.

Durable and Versatile Deployment with Huawei eKit AP761 WiFi 6 Access Point with PoE

Compact yet powerful, the Huawei eKit AP761 is designed for versatile deployment. Its durable build allows it to be mounted on walls, ceilings, or poles with ease. Thanks to its lightweight construction and robust surge protection, it fits seamlessly into diverse environments, from industrial facilities to outdoor entertainment venues, ensuring continuous high-performance connectivity.

Why Choose the Huawei eKit AP761 WiFi 6 Access Point with PoE

The Huawei eKit AP761 WiFi 6 Access Point with PoE stands out as an ideal solution for businesses seeking reliable, scalable, and future-ready wireless networks. Its combination of high-speed Wi-Fi 6 performance, support for large numbers of users, rugged design, and comprehensive security makes it a top choice for enterprises, campuses, and commercial deployments that require both indoor and outdoor coverage.

Get Your Huawei eKit AP761 WiFi 6 Access Point with PoE Today

Upgrade your network infrastructure with the Huawei eKit AP761 WiFi 6 Access Point with PoE and experience the benefits of fast, secure, and reliable wireless connectivity. Designed for demanding environments, this AP ensures consistent high performance and long-lasting durability. Order now and empower your organization with the next generation of wireless technology from Huawei.
