Fanvil A233 Horn Speaker

Fanvil A233 Horn Speaker Key Features

• Commercial-grade IP horn speaker
• SIP-enabled network audio terminal
• 30W maximum speaker output
• Up to 120dB maximum sound pressure level
• 350Hz–7.5kHz frequency response
• Built-in omnidirectional microphone
• 2 SIP lines
• Supports SIP and ONVIF
• Supports multicast broadcasting
• Up to 20 multicast partitions
• 24MB built-in audio storage
• Scheduled audio broadcasting
• Emergency broadcasting support
• Two-way intercom functionality
• PoE and PoE+ power support
• DC 24V power option
• 10/100Mbps Ethernet
• IP66 waterproof and dustproof protection
• U-bracket installation
• Remote volume adjustment
• Suitable for outdoor and industrial environments

Fanvil A233 Horn Speaker Introduction

The Fanvil A233 Horn Speaker is a commercial-grade IP audio solution designed for public address systems, emergency announcements, paging, and two-way communication. It can operate independently or integrate with IP PBX, unified communication, surveillance, access control, and other network-based systems.

With a high-output horn design, IP66 protection, SIP support, and PoE connectivity, the A233 is suitable for demanding environments such as factories, warehouses, schools, campuses, transport facilities, and outdoor public spaces.

Fanvil A233 Horn Speaker Price in Kenya

Fanvil A233 Horn Speaker Key Specifications

Fanvil A233 Horn Speaker Performance

The A233 is designed to deliver loud and clear audio across large or noisy areas.

• Up to 30W output when powered through DC 24V
• Up to 120dB maximum sound pressure level
• 350Hz–7.5kHz frequency response
• Supports HD voice with G.722 and Opus codecs
• Supports MP3 and WAV audio broadcasting
• Built-in microphone for two-way communication
• Full-duplex intercom functionality
• Scheduled and emergency broadcasts
• Remote volume control

Fanvil A233 Horn Speaker Network Connectivity

The A233 uses Ethernet connectivity to integrate with network-based communication systems.

• 10/100Mbps Ethernet
• SIP 2.0 support
• RTP/RTCP/SRTP
• IPv4 and IPv6
• DHCP
• PPPoE
• VLAN
• LLDP
• QoS
• L2TP and OpenVPN
• HTTP/HTTPS
• FTP/TFTP
• TR-069

Its network capabilities make it suitable for integration with IP PBX systems, paging systems, surveillance platforms, and other network communication infrastructure.

Fanvil A233 Horn Speaker Audio Broadcasting

The A233 supports several broadcasting functions for organizations that need centralized or scheduled announcements.

• Public address broadcasting
• Emergency announcements
• Scheduled broadcasting
• Multicast broadcasting
• Up to 20 multicast partitions
• Pre-recorded audio playback
• MP3 and WAV support
• 24MB internal audio storage
• Priority management
• Custom audio files
• Remote volume adjustment

Fanvil A233 Horn Speaker Power Options

The speaker supports multiple power options, providing flexibility during installation.

• PoE power
• PoE+ power
• DC 24V/2A power
• PoE provides up to 8W speaker power
• PoE+ provides up to 15W speaker power
• DC 24V/2A provides up to 30W speaker power

PoE and PoE+ can simplify installation by allowing network connectivity and power to be delivered through Ethernet.

Fanvil A233 Horn Speaker Build Quality & Design

The A233 uses a rugged horn-shaped enclosure designed for demanding indoor and outdoor installations.

Its IP66 protection rating provides protection against dust and water, making it suitable for many outdoor environments. The included U-bracket allows the speaker to be mounted securely on suitable surfaces.

The speaker measures approximately 285 × 285 × 205mm and comes in a white finish.

Fanvil A233 Horn Speaker Ideal Use Cases

This horn speaker is best suited for:

• Factories
• Warehouses
• Schools and campuses
• Transport facilities
• Outdoor public spaces
• Industrial facilities
• Shopping centers
• Security installations
• Emergency alert systems
• Public address systems
• IP paging systems
• Access control environments
• Fire alarm integration
• Large commercial premises

Fanvil A233 Horn Speaker Pros and Cons

Fanvil A233 Horn Speaker FAQs

What is the Fanvil A233?
The Fanvil A233 is a commercial-grade IP horn speaker designed for public address, paging, emergency broadcasting, and two-way communication.

How powerful is the Fanvil A233?
The speaker can deliver up to 30W when powered through DC 24V/2A.

What is the maximum sound level?
The A233 can reach up to 120dB maximum SPL.

Does the Fanvil A233 support SIP?
Yes. It supports SIP 2.0 and can integrate with compatible IP communication and PBX systems.

Is the Fanvil A233 suitable for outdoor use?
Yes. Its IP66 protection rating makes it suitable for many outdoor and industrial environments.

Does it support PoE?
Yes. The A233 supports both PoE and PoE+, as well as DC 24V power.

Does the A233 have a microphone?
Yes. It has a built-in omnidirectional microphone for two-way communication and intercom applications.

Can the A233 play recorded announcements?
Yes. It supports stored audio files, scheduled broadcasting, emergency announcements, and MP3/WAV playback.

How many SIP lines does it support?
The A233 supports 2 SIP lines.

How much does the Fanvil A233 Horn Speaker cost in Kenya?
The price is KSh 23,000.

Fanvil A233 Horn Speaker Conclusion

The Fanvil A233 Horn Speaker is a powerful IP audio solution designed for public address, emergency broadcasting, paging, and two-way communication. With up to 30W output, 120dB SPL, SIP connectivity, PoE support, multicast broadcasting, built-in audio storage, and IP66 protection, it is well suited for demanding commercial and outdoor installations.

At KSh 23,000, the Fanvil A233 is a practical choice for schools, factories, warehouses, businesses, security installations, and organizations requiring reliable network-based public address and paging.
