Dahua ITSJC-2303-DC12 Anti-smashing Radar Overview
The Dahua ITSJC-2303-DC12 is a 79 GHz anti-smashing radar designed for intelligent traffic and smart parking systems. It prevents barrier arms from hitting vehicles or pedestrians by detecting objects in the barrier’s path. With high-precision microwave measurement and digital signal processing, it offers fast response, high accuracy, and stable performance in complex environments.
Dahua ITSJC-2303-DC12 Anti-smashing Radar Specifications
| Component | Details |
|---|---|
| Model Number | ITSJC-2303-DC12 |
| Frequency Range | 77 GHz – 81 GHz |
| Emission Power | ≤ 10 mW |
| Beam Width | Vertical: ±10°, Horizontal: ±36° |
| Response Time | 50 ms |
| Detection Range | 0.3 m – 6 m (0.98 ft – 19.7 ft) |
| Technology | Microwave measurement + digital signal processing |
| Functions | Anti-smashing detection for barrier arms (advertising, fence, straight, folding) |
| Features | Adjustable detection distance and width, interference filtering, auto scene adaptation |
| Connectivity | RS-485 interface (connects to cameras for logs and parameters) |
| Updates | Firmware updates via serial port or mobile app (Wi-Fi connection) |
| Operating Voltage | DC 12 V |
| Applications | Parking barriers, toll gates, access control systems |
Dahua ITSJC-2303-DC12 Anti-smashing Radar Price in Kenya
| Product Description | Price Range (KES) |
|---|---|
| Dahua ITSJC-2303-DC12 Anti-smashing Radar | KSh 18,000 – 22,000 |
Dahua ITSJC-2303-DC12 Anti-smashing Radar Design and Build
-
Compact radar module for easy integration with barriers
-
Automatic environment adaptation for complex scenes
-
Rugged design suitable for outdoor installations
-
Supports cloud commissioning and firmware updates
Dahua ITSJC-2303-DC12 Anti-smashing Radar Performance
-
Fast response time (50 ms) ensures safety and reliability
-
Adjustable detection range for different barrier types and environments
-
Interference filtering algorithm reduces false alarms
-
Stable operation with high-precision microwave technology
Dahua ITSJC-2303-DC12 Anti-smashing Radar Ideal User Cases
-
Parking lots: Preventing barrier arms from hitting vehicles
-
Toll stations: Ensuring safe vehicle passage
-
Commercial complexes: Automated access control
-
Industrial facilities: Secure entry and exit monitoring
Dahua ITSJC-2303-DC12 Anti-smashing Radar Pros and Cons
| Pros | Cons |
|---|---|
| High accuracy and fast response | Limited detection range (max 6 m) |
| Adjustable detection distance and width | Requires DC 12 V power supply |
| Works with multiple barrier types | Needs RS-485 integration for camera logs |
| Firmware updates via mobile app | – |
Dahua ITSJC-2303-DC12 Anti-smashing Radar FAQs
1. What barriers is it compatible with? Advertising barriers, fence arm barriers, straight arm barriers, and folding arm barriers.
2. How does it prevent accidents? It detects vehicles or pedestrians in the barrier’s path and prevents the arm from lowering.
3. Can it be updated remotely? Yes, via serial port or mobile app (Wi-Fi connection).
4. What is the detection range? 0.3 m – 6 m.
5. Does it integrate with cameras? Yes, via RS-485 for logs and parameter monitoring.
