Blackmagic Design ATEM Production Studio 4K Live Switcher

• Supports 10-Bit NTSC/PAL/HD/UHD 4K
• Supports 4K Resolution over SDI or HDMI
• 4 x 6G-SDI & 4 x HDMI Inputs (4K/HD/SD)
• Tri-Sync/Blackburst Ref. Sync Input
• 8 x Built-In Frame Synchronizers
• Multiview Monitoring in HD
• Program Outputs in SD/HD/4K HD
• 1 x Upstream & 2 x Downstream Keyers
• Audio: 10 x Input, 2-Channel Mixer
• Hardware or Software Mac/Windows Control

Description

The Blackmagic ATEM Production Studio 4K Live Switcher is a live event multicamera production switcher with eight individual Ultra HD inputs built into a 1 RU chassis. Supporting NTSC/PAL/HD and Ultra HD video formats via four Single-Link 6G-SDI and four 4K HDMI inputs, the Blackmagic ATEM Production Studio 4K Live Switcher connects to a wide range of cameras and sources, delivering a single program stream in SD, HD, or UHD 4K video. All this is done live and in real time with no rendering required.

The Blackmagic ATEM Production Studio 4K Live Switcher features a reference video input for synchronizing the switcher to other equipment using tri-level or Blackburst Sync. Each input also features its own frame synchronizer, which allows you to use cameras that do not feature Genlock as well as input video from computer sources. The Blackmagic ATEM Production Studio 4K Live Switcherr can handle inputs from all inputs at the same time.

The Blackmagic ATEM Production Studio 4K Live Switcher provides six video outputs that are always active. Featuring one SDI and one HDMI Program output, both of which deliver SD/HD/UHD 4K, with one Aux SD/HD/UHD 4K output that can deliver a clean program feed without any downstream effects, as primary outputs. The Blackmagic ATEM Production Studio 4K Live Switcher also features an HD-only program output signal for monitoring on an SDI-equipped HD monitor. Multiview monitoring is also HD only over dedicated SDI or HDMI output, and multiview allows you to view the program, preview, six active inputs, and two graphic channels (media players) on one screen at the same time. The Blackmagic ATEM Production Studio 4K Live Switcherr features one upstream and two downstream keyers for real-time effects and composites in Ultra HD, with 10-bit processing. The two downstream keyers allow you to use two graphics/logos/titles/lower thirds from up to twenty stored graphics in a wide variety of formats.

A built-in two-channel audio mixer handles the embedded HDMI and SDI audio from the six active video inputs as well as audio from the balanced and unbalanced analog audio inputs to provide you flexibility and creative audio options. Audio output is embedded in the SDI and HDMI stream, as well as available via balanced audio outputs. Either a Mac or Windows computer running the included ATEM Software controls the switcher’s operation and settings. For those who like the feel of a physical control panel, available ATEM Broadcast Panels, connected via the Ethernet port, also control all the features of the switcher. Illuminated front panel buttons allow you to locally select the Aux output, while a 2″ LCD screen built into the front of the unit allows you to see the Aux output for instant confirmation of the correct output.

The Blackmagic ATEM Production Studio 4K Live Switcher Video

• The ATEM Production Studio Live 4K switcher supports UHD 4K video (3840 x 2160) and has eight video inputs, all of which can be active simultaneously.
• The Blackmagic ATEM Production Studio 4K Live Switcherr features four single-link 6G-SDI and four HDMI 4K inputs, which allows you to connect SD/HD/Ultra HD and computer-based signal to the switcher. Although the switcher takes reference video in for sync timing so it can interface with other post-production equipment, each input has its own frame synchronizer, which enables you to use cameras that do not have genlock capability or for the input of computer sources such as Keynote or PowerPoint presentations.
• The capture video format is set by the user and must be the same across each input, as the switcher cannot scale different input formats to match the project format.

The Blackmagic ATEM Production Studio 4K Live Switcher Audio

• The Blackmagic ATEM Production Studio 4K Live Switcher includes a built-in audio mixer that allows you to adjust the audio embedded in the SDI and HDMI signals. With 10 inputs available, the two-channel mixer can also adjust levels of both the balanced and unbalanced analog inputs.

The Blackmagic ATEM Production Studio 4K Live Switcher has a Six Video Outputs

•  The Blackmagic ATEM Production Studio 4K Live Switcher features three program outputs for the final video, delivering SD/HD/Ultra HD via both a 6G-SDI port and HDMI 4K connector. The third program output is an HD-SDI only port (Ultra HD is automatically down-converted).
• Two multiview outputs allow you to see program, preview, the six live inputs, and the two graphic channels on one screen at the same time. There is one each SDI and HDMI connector which feeds the multiview output to HD monitors.
• The Blackmagic ATEM Production Studio 4K Live Switcher  features an SDI Aux output that is capable of delivering the program out feed with or without the downstream keyer effects in SD, HD, and Ultra HD. Control of the Aux output is by front-mounted panel buttons and a built-in 2″ LCD screen for immediate confirmation of the Aux output.

The Blackmagic ATEM Production Studio 4K Live Switcher allows Multiview Monitoring

Multiview allows you to view the program, preview, six live inputs, and two media players side by side. You can also add custom labels that make it easy to identify each input.

The Blackmagic ATEM Production Studio 4K Live Switcher Effects

The Blackmagic ATEM Production Studio 4K Live Switcher  features an upstream keyer that includes independent chroma, pattern, shape, and luma keying all at Ultra HD resolution with 10-bit processing. Two downstream keyers allow you to add graphics, lower thirds, titles, and logos for a polished live production.

The Blackmagic ATEM Production Studio 4K Live Switcher has a Control Interface

• The ATEM 4K switcher uses an Ethernet connection to interface with control surfaces such as the optional ATEM 1 M/E and 2 M/E Broadcast Panels.
• You can also control rhe Blackmagic ATEM Production Studio 4K Live Switcher by using the included ATEM Software Control software from a Mac or Windows computer over Ethernet. You can control all production settings of the switcher as well as directly import graphics from your computer into the switcher’s media pool.
• You set the format for each project you are working on, from SD to HD to UHD 4K, selecting resolution and frame rate. This is accomplished by using either the included software for Mac/Windows PC or via the ATEM 1 M/E or ATEM 2 M/E Broadcast Panel.
• Using the Ethernet port on the switcher allows you to connect control surfaces directly to the Blackmagic ATEM Production Studio 4K Live Switcher, or you can control the switcher across a network.
• The Blackmagic ATEM Production Studio 4K Live Switcher features a mini-USB port that is used for software updates and to set the switcher’s chassis IP address, which can only be done by using a computer running the ATEM Switcher Utility connected to the switcher’s USB port.

The Blackmagic ATEM Production Studio 4K Live Switcher is instilled with Rack Mount

The Blackmagic ATEM Production Studio 4K Live Switcher is 1 RU in height and has built-in rack mount ears, for mounting in a production road case or a post-production facility.
