APC Easy UPS SRV3KRIRK 3000VA RM 230V Rail Kit

Key Features – APC Easy UPS On-Line SRV3KRIRK 3000VA Rackmount (230V)

• Capacity: 3000 VA / 2400 W continuous power

• Topology: Double-conversion online UPS with pure sine wave output and zero transfer time

• Outlets: 6x IEC C13 and 1x IEC C19 outlets

• Form Factor: 2U rackmount with included rail kit

• Efficiency: Up to 94% in ECO mode

• Battery: Maintenance-free sealed lead-acid; ~4-hour recharge to 90%

• Display: LCD interface with mimic diagram for real-time monitoring

• Connectivity: USB, RS-232 ports, and SmartSlot™ for optional network management card

• Bypass: Automatic internal bypass rated for 125% load

• Warranty: 2 years repair-or-replace with connected equipment protection

• Size & Weight: Dimensions: 437 × 86 × 632 mm; Weight: 27.6 kg

APC Easy UPS On-Line SRV3KRIRK – Reliable Power for Critical Systems

The APC Easy UPS On-Line SRV3KRIRK is a high-performance 3000 VA (2400 W) double-conversion online UPS, designed to provide uninterrupted power to critical IT infrastructure. Its 2U rackmount form factor, coupled with an included rail kit, ensures easy integration into standard server racks, making it ideal for data centers, server rooms, and network closets.

Pure Sine Wave Output with Zero Transfer Time

Utilizing double-conversion technology, this UPS continuously converts incoming AC power to DC and then back to AC, delivering a pure sine wave output. This process ensures that connected equipment receives clean and stable power, free from voltage fluctuations and electrical noise, which is crucial for sensitive devices like servers, storage systems, and networking equipment.

High Efficiency and Energy Savings

Operating with up to 94% efficiency in ECO mode, the SRV3KRIRK minimizes energy consumption and reduces operational costs. The UPS automatically switches to ECO mode when utility power is stable, bypassing unused internal components to achieve high operating efficiency without sacrificing protection

Comprehensive Monitoring and Management

The multifunction LCD interface provides real-time information on input/output voltage, load, battery status, and operational mode. For remote monitoring and management, the UPS includes USB and RS-232 ports, along with a SmartSlot™ for an optional network management card, enabling integration with centralized management platforms like EcoStruxure IT

Robust Battery Management

Equipped with maintenance-free sealed lead-acid batteries, the SRV3KRIRK offers reliable backup power during outages. The intelligent battery management system ensures optimal battery performance and longevity, with a typical recharge time of approximately 4 hours to 90% capacity.

Automatic Bypass and Restart

In the event of a UPS overload or fault, the automatic internal bypass allows utility power to supply connected loads, maintaining power continuity. Additionally, the UPS features automatic restart of connected equipment upon the return of utility power, ensuring minimal downtime.

Conclusion

The APC Easy UPS On-Line SRV3KRIRK is a robust and efficient solution for safeguarding critical IT equipment against power disturbances. Its double-conversion technology, high efficiency, comprehensive monitoring capabilities, and reliable battery management make it an excellent choice for businesses seeking to ensure the continuity and protection of their operations.
